Automatic wrapping machine

Performance

• 30 pallets per hour production.

• 86″ maximum load wrap height -118″ extended height available.

• 3800lb maximum load weight capacity.

• 250% power pre-stretch film carriage for improved efficiency.

• Auto film attach, hot weld seal, and film auto cut.

Features

• Frequency controller for rotation speed adjustment

• Frequency controller for carriage speed adjustment

• Photocell for pallet height detection

• Safety stop at the base of the carriage

• Stop at 0 position

• Power board IP54

• Password lock mode

• Adjustable parameters by the control panel: cycle selection, bottom wrap counts, top wrap counts, rotation speed, carriage speed going up, carriage speed going down, film tension

• 10 wrap programs can be saved by the customer

• 4 cycle types: automatic, semimanual, semiautomatic, and fixed height

• Acoustic warning at the cycle beginning and stop

• Wrapped pallet counter

• Autodiagnostic

• Powder coating

• Soft start and stop
