Belt Drive Pellet Mill

Belt Drive Pig and Livestock Animal Feed Small Ring Die Pellet Making Machine with CE Certification

GFZL Series Belt Drive Pellet Mill

Highly efficient pellet mill for poultry feed, livestock feed and aquafeed production.

● High efficiency

Stable two-motor timing belt drive, large torque but low noise; optimized area-to-power ratio of ring die, maximum output; triple rollers and cutters and stable production.

● Hygiene and safety

CE certified standard design and available stainless steel conditioner for feed, human and machine safety.

● Flexible production

Wide product range: Φ0.8mm~Φ12mm pellets; conditioner with molasses and steam adding function.

● User-friendly operation

Hydraulic system for die change and roller adjustment (optional), quick and precise operation; auto-lubrication system (optional) and die & roller lifting device, saved labor; on-site touch screen control.

Model	Capacity（t/h）	Power(kw)
GFZL350	2.0-6.0	30x2/37x2
GFZL350X	0.1-2.0	30x2/37x2
GFZL420/460	5.0-12.0	55x2
GFZL420X	2.0-3.0	55x2
GFZL550	8.0-16.0	55x2/75x2
GFZL550X	3.0-5.0	55x2/75x2
GFZL630	10.0-25.0	90x2/110x2
GFZL800	10.0-32.0	132x2/160x2
