Single Screw Extruder

High-efficient extruder for aquafeed, food, pet food and raw material treatment.

GFSE Series Single-Screw Extruder

High-efficient extruder for aquafeed, food, pet food and raw material treatment.

● Simple operation

Leading extrusion technology and intelligent control; by-pass for avoiding blockage; simple operation, precise and reliable.

● High efficiency

DDC conditioner and optimal modular extruder screw & chamber, minimum Specific Mechanical Energy (SME) input; recoverable thermal energy, maximum energy utilization; unique suspending cutter, replacement and adjustment without downtime.

● Wide production range

Controllable temperature, pressure and density thanks to modularized design and many add-ons, minimizing reconfiguration acquired.

● Satisfying product quality

Uniform extruded pellets with high fat absorption, unique visual appearance, environmental friendly and sustainable.

Model	Main power（kw）	Screw Dia.（mm)	Foalting feed Capacity（t/h)	Pef food Capacity（t/h)	Sinking feed Capacity（t/h)
GFSE135	90	135	1.0-2.2	1.0-2.2	0.5-1.0
GFSE165	160	165	4.0-6.0	4.0-6.0	1.5-4.0
GFSE215	250/315	215	6.0-9.0	6.0-9.0	2.5-5.5
GFSE265	315	265	6.0-12.0	6.0-12.0	3.0-6.0
